FRCABLE Tinned  Copper PV Wire Single Layer UL 4703 2KV

Product Type

PV cable

UL PV Wires

FRCABLE Tinned  Copper PV Wire Single Layer UL 4703 2KV

UL
25 YEARS_edited_edited.jpg
  • Conductor:

  • Insulation:

  • Rated temperature:

  • Rated voltage:

Stranded bare copper

Cross-linked compound,  Black, Red or White

-40℃ to 90℃

1000/2000V DC

  • Reference Standard:

UL 4703 PV wire

UL 44 Thermoset-insulated cables

UL 854 Service-entrance cables

Application

The FRCABLE® PV Wire is UL 4703 certified and designed for the connection of PV panels.Engineered to withstand harsh outdoor environments, the UL 4703 cable boasts superior UV resistance, Ozone resistance,and water resistance, ensuring a reliable and long-lasting connection within your solar power system.

Advantages

  • Electron Beam Cross Linked compound, XLPE/XLPE.

  • Resistance against UV, Ozone, Fluids, Oil, Salt & General Weathering.

  • Halogen Free, Flame Retardant, Low Smoke Emission.

  • 25 years of lifetime expectancy.

  • Suitable for direct burial.

Technical Data

  • Rated  temperature:                                                 -40℃ to 90℃

  • Rated  voltage:                                                             1000/2000V DC

Item Data

Item description

Part No.

Color

AWG

(approx)

Insulation Thickness

(mm)

Jacket Thickness

(mm)

Outer  Dia

(mm)

Conductor Resistance

Max. mΏ/m

20107012704

Black

12

1.14

0.76

6.20±0.2

5.64

20107012805

Red

12

1.14

0.76

6.20±0.2

5.64

20107010706

Black

10

1.14

0.76

6.82±0.2

3.546

20107010807

Red

10

1.14

0.76

6.82±0.2

3.546

20107008708

Black

8

1.39

0.76

8.05±0.2

2.23

20107008809

Red

8

1.39

0.76

8.05±0.2

2.23

20107006710

Black

6

1.39

1.14

9.82±0.2

1.403

20107006811

Red

6

1.39

1.14

9.82±0.2

1.403

Downloads

BEST SOLAR CABLE FACTORY_edited.jpg

FAQs

1. What is a single-layer UL 4703 tinned copper PV wire?
This is a high-voltage photovoltaic (PV) wire with a tinned copper conductor and single-layer insulation, certified under UL 4703. It is rated for 2KV DC and used for interconnecting components in solar power systems.

2. What are the benefits of using tinned copper in PV cables?
Tinned copper resists corrosion better than bare copper, especially in humid, salty, or chemically aggressive environments. It also maintains excellent electrical conductivity and extends cable life in outdoor solar applications.

3. What does UL 4703 certification guarantee?
UL 4703 certification ensures the cable meets strict U.S. safety standards for voltage capacity, flame resistance, UV stability, and long-term performance in solar installations.

4. Where is this single-layer PV wire typically used?
It is ideal for interconnections between solar modules, inverters, combiner boxes, and charge controllers in both rooftop and utility-scale photovoltaic systems.

5. Is this cable suitable for outdoor or underground installations?
Yes. The UV-resistant insulation allows for outdoor use, and it is durable enough for conduit and direct burial installations, depending on site requirements.

6. What is the voltage and temperature rating of this cable?
This cable is rated for 2000V DC, with a temperature range of -40°C to +90°C in wet conditions, and up to +150°C in dry conditions, supporting reliable use in harsh environments.

7. What sizes are available for the FRCABLE tinned copper PV wire?
We offer a full range of sizes from 10 AWG to 500 KCMIL, supporting a wide variety of current loads and system designs.

8. Why choose FRCABLE for your tinned copper UL 4703 solar cable needs?
As a leading PV cable manufacturer in China, FRCABLE delivers UL-certified, corrosion-resistant solar cables with stable quality, fast delivery, global support, and OEM/ODM customization options for solar EPCs and installers.
